Products Character
1.Operates easily: one-botton leaking tests automatically, the text demonstrats leak testing information, the defective products reject the production line automatically.
2. Constructs firmly: The steel plate works fuselage, the fluctuation place unifies the guide pillar and the lead screw.
3. The leak testing precision is high, the speed is quick: using the high accuracy digital pressure sensing index error is to press the leak testing, the laser probe head.
4. The price advantage: our leak testing machine is considered today on the field of plastic container for leak testing amchine most to have the performance-to-price ratio, obtained the test and confirmation from the global customers in the past several years.
Technical Parameters
Model | HJ-LTL100 | HJ-LTS1 | HJ-LTM1 | HJ-LTM2 | HJ-LTM3 | HJ-LTM4 |
The quantity of Location | 1 | 1 | 1 | 2 | 3 | 4 |
The power of Motor | 100W/220V | 90W/220V | 90W/220V | 90W/220V | 100W/220V | 100W/220V |
The speed of Transportation tape(rice/second) | 0-15 | 0-15 | 0-15 | 0-15 | 0-15 | 0-15 |
The speed of the leak testing (only/hour) working speed | 0-1L | 1800 | 1800 | 1800 | 3200 | 4000 | 6000 |
1-2L | 1500 | 1500 | 1500 | 2800 | 3200 | 5000 |
3-5L | 900 | --- | 1200 | 200 | 2600 | --- |
5-8L | 700 | --- | 900 | 1600 | --- | --- |
8-15L | 600 | --- | 800 | 1200 | --- | --- |
10-80L |
|
|
|
|
|
|
The maximum outer diameter of observable bottle's mouth(mm) is removable | 75 | 30 | 65 | 65 | 40 | 40 |
The extreme breadth of observable bottle(mm) | 400 | 200 | 200 | 160 | 150 | 150 |
The most greatly highly of observable bottle(mm) | 600 | 400 | 400 | 400 | 200 | 200 |
The greatest volume of observable bottle(L) | 80 | 15 | 15 | 8 | 5 | 2 |
Air pressure(Mpa/cm2) | 0.6 | 0.5 | 0.5 | 0.5 | 0.6 | 0.6 |
Total power consumption(w) | 110 | 110 | 110 | 110 | 110 | 120 |
Weight (kg) only |
|
|
|
|
|
|
External dimensions L*W*H(M) packing case is empty | 1.65*0.8*1.7 | 1.65*0.6*1.65 | 1.65*0.6*1.65 | 1.65*0.6*1.65 | 1.65*0.6*1.65 | 1.65*0.6*1.65
|
