1000liter HDPE Ibc Tote Plastic Container Extrusion Blow Mould Making Machine

Share to:
Extrusion blow molding machine can produce 1000L hdpe plastic ibc tank container
Availability:

4

Model BSM130-1000L, BSM140-2000L,BSM140-3000L,BSM150-5000L
Fininshed Product
Plastic jerry cans, bottles, pots, toys and kettles etc.
Max. product volume 5000L
Plastic material HDPE
Head No. Single
Multi-extrusion layer possible 1-3 layer
Auxiliary equipments blow mould, mixer, vacuum auto-loader, dryer, crusher, water & fans chiller, air compressor, conveyor system for deflashing parts, conveyor system for finished product delivery, leakage tester…

IBC tankIBC TANK MACHINE产品 02

CHARACTER



1. The machine is high speed, high quality. The clamping system is with nether bending arm type. It can make sure the clamping force to be enough.



2. The mahine is with 100 point parison control system and with one set of seperate oil tank system for MOO system.



3. The machine is with MITSUBISHI PLC and SIMENS operation screen.



4. The machine is with FESTO pneumatic parts.



5. The machine is with YUKEN hydraulic pump and valves.

4



TECHNOLOGY PARAMETERS



Machine Model

BSM130-1000L

BSM140-2000L

BSM150-5000L

Product volume

1000L

2000L

5000L

Machine dimension

8*4*6.3m

11*4.8*6.5m

14*4.8*8m

Machine weight

22T

28T

50T

Screw diameter

130mm

140mm

150mm

L/D ratio

30

30

30

Extrusion Motor power

132*2kw

132*2kw

132*2kw

Output of HDPE

350*2kg/h

350*2kg/h

350*2kg/h

Max. mould size

1500*1700mm

1800*1900mm

2300*2500m

Capacity of accumulator head

40L

80L

220L

Platen distance

800-2300mm

1040-3200mm

1600-4000mm

Compressed air needed

1.0m3/min

2.0m3/min

5.0m3/min

Cooling water needed

0.4Mpa

0.4Mpa

0.4Mpa
