Shampoo filling machine production line
Our automatic servo piston filling machine is extremely flexible filler, is capable of filling accurately and rapidly any viscous material,such as detergent liquid，shampoo, hand soap,dishwashing liquid, shower gel and so on.
1. Using servo motor control, fast filling speed and precise filling.
2. Full touch screen control. Convenient operation and quick adjustment. It is convenient and fast to switch bottle types without any tools. And can save bottle type data. The next filling can be filled with one key.
3. It can fill bottles of different shapes and specifications, which solves the problem of difficult filling of special-shaped bottles. This machine is equipped with a piston and a three-way valve, and the washing machine does not need to be disassembled and cleaned quickly and conveniently. The bottle guard can be adjusted quickly. One-click in place.
4 This equipment is fully automatic and intelligent. You only need to save the basic parameter setting number of the product. Next time you need to produce this product, you only need to call up the saved number.
4. The size, height and position of the bottle do not need to be adjusted manually, they are all automatically adjusted. The equipment will automatically detect the running speed of the bottle, and automatically correct the position of the bottle mouth for synchronous movement filling. For example, it only takes a few seconds to change the product from 100ML to 2000ML, which is especially suitable for the production of products with many varieties and small quantities.
5. Four capacity cylinders are used to ensure the filling speed
6. The part in contact with the material is made of sUS316, and the other stainless steel parts are made of 304
Filling machine description
| Heads | 2 | 4 | 6 | 8 | 10 | 12 | 16 |
| Range（ml） | 100-500,100-1000,1000-5000 |
| Capacity（bpm）base on 500ml | 12-14 | 24-28 | 36-42 | 48-56 | 60-70 | 70-80 | 80-100 |
| Air Pressure（mpa） | 0.6 |
| Accuracy（%） | ±0.1-0.3 |
| Power | 220VAC SINGLE PHASE 1500W | 220VAC SINGLE PHASE 3000W |
Filling machine parts brand
| No. | ITEM | SUPPLIER | Brand |
| 1 | Touch screen | Taiwan | Eview |
| 2 | PLC | Japan | Siemens |
| 3 | Photo sensor for bottles | Japan | Panasonic |
| 4 | solenoid valve | Taiwan | SHAKO |
| 5 | Level button | Mexico | JOHNSON CONTROLS |
| 6 | Piston cylinder | Taiwan | AIRTAC |
| 7 | Servo motor | France | Schneider |
| 8 | angle seat Valve | Jointed | BURKERT |
| 9 | Other divices | Taiwan | AIRTAC |
| 10 | Power button | Taiwan | Mean Well |
| 11 | Button | France | Schneider |
| 12 | frequency converter | France | Schneider |
| 13 | bottle- transport motor | China | Huangyan |
| 14 | Speed reducer | China | Jiao xing |
| 15 | Relay | Japan | Omron |
Contact us , get the shampoo filling machine video.
E-mail: huanmachinery@vip.163.com
Whatsapp/Wechat: 0086 15298809298
